Argument
Housing Material /Color | Thermoplastic / Black |
Metal Shell | SUS201 |
Terminal Material | Copper Alloy |
Number of Contacts | 9 Pin |
Rating Current | 1.5A |
Rating Voltage | 30V DC |
Contact Resistance | 30MΩ MAX |
Dielectric withstanding Voltage | 500V AC / Minite |
Insulation Resistance | 100MΩ MIN |
Mated Force | 10N Min Initial, 8N Min after test |
Unmated Force | 35N MAX |
Temperature | - 40°C ~ + 85°C |
Durability | 5,000 cycles |
