The product is a 4 Pin PH2.0 90-degree DIP header, made of PA46 material and compliant with RoHS environmental standards. Designed for right-angle (90-degree) insertion, it is suitable for compact PCB connections, offering reliable electrical performance and mechanical stability. It is widely used in electronic devices, industrial control systems, and consumer electronics.
Features
Environmental Compliance: RoHS compliant, free from hazardous substances, ensuring safety and environmental protection.
High Temperature Resistance: PA46 material offers excellent heat resistance, making it suitable for high-temperature operating environments.
Compact Design: 90-degree DIP right-angle connector design saves space and facilitates high-density wiring.
Reliable Connection: 4Pin PH2.0 interface ensures stable electrical connections and signal transmission.
High Mechanical Strength: PA46 material provides superior mechanical strength and durability, extending service life.
Argument
Material of Main Part/Color | PA46/Beige |
Number of Contacts | 4 Pin |
Rated Current | 3.0A/PIN |
Rated Voltage | 250V AC/DC |
Contact Resistance | 30mΩ MAX. |
Withstand Voltage | 800V AC (1min) |
Insulation Resistance | 1000MΩ MIN. |
Operating Temperature | -25℃ ~ +85℃ |
Core Technology
Key Words:
4Pin PH2.0 header, 90-degree DIP, PA46 material, RoHS compliant, right-angle connector, high-temperature resistant
Core Advantages:
The 90-degree insertion design optimizes space utilization while maintaining plugging stability and contact reliability.
Technical Features:
High-precision injection molding technology ensures accurate pin spacing (PH2.0) and dimensional precision of the right-angle structure.
