The MTFP22-815STW-01A72 is a 15Pin DIP vertical FPC connector compliant with RoHS environmental standards. Designed for electronic devices requiring high-reliability connections, it delivers stable signal transmission and mechanical durability for applications in consumer electronics, industrial controls, and medical equipment.
Features
DIP Vertical Design: Compatible with through-hole technology (THT), offering enhanced mechanical strength.
High-Speed Transmission: Dual-channel differential signaling supports 10Gbps data transfer (USB3.2 Gen2).
EMI Shielding: Full metal-shielded housing reduces electromagnetic interference.
High-Current Support: Compliant with USB PD 3.0, enabling 20V/5A 100W fast charging.
Extended Temperature Range: Operates from -55℃ to +85℃, suitable for diverse environments.
Argument
| Material of Main Part/Color | SUS Shell+ Black LCP |
| Number of Contacts | 16 Pin |
| Rated Current | Vbus and GND 5A. Other Pins 0.25A MIN. |
| Rated Voltage | 20V DC |
| Contact Resistance | Vbus and GND 30mΩ MAX. Other PINS 50mΩ MAX. |
| Withstand Voltage | 100V AC (1Min) |
| Insulation Resistance | 100MΩ MIN. |
| Insertion Force | 5-20N |
| Withdrawal Force | 8-20N |
| Service Life | 10,000 Times |
| Operating Temperature | -40℃~ +85℃ |
This 15 pin FPC connector adopts a precision-engineered contact system to ensure stable mating with flexible flat cables. The through-hole DIP structure anchors firmly to the PCB, reducing the risk of solder joint fatigue in high-volume or long-running products.
The housing is designed to guide the FPC smoothly during insertion, minimizing alignment errors during assembly and improving production efficiency in automated or semi-automated lines.
The connector is built to maintain stable electrical performance throughout its service life. Carefully selected contact materials and plating options ensure low contact resistance and reliable conductivity across all signal lines.
Mechanical durability is optimized for repeated insertion cycles, ensuring long-term reliability in products that require maintenance, upgrades, or flexible cable movement.
Typical performance characteristics include:
Stable contact resistance under repeated mating
Reliable solder retention strength for DIP mounting
Consistent signal transmission in compact layouts
Resistance to thermal and mechanical stress during operation
The 15 pin 1.25mm DIP FPC connector is widely adopted in applications that demand stable connections and strong PCB fixation, including:
Consumer electronics such as display modules and control panels
Industrial control systems and automation equipment
Automotive electronic modules
Smart home devices
Communication terminals
Instrumentation and monitoring equipment
Portable devices with internal flexible cable connections
These applications often require connectors that remain available for years, making long-term supply reliability a key selection factor.
This FPC connector is particularly suitable for customers purchasing in large quantities, such as:
OEM manufacturers with stable production schedules
EMS and contract assembly factories
Automotive and industrial electronics suppliers
Brands managing long product life cycles
Distributors supplying standardized connector components
For these procurement groups, consistency, pricing stability, and supply continuity are often more important than short-term customization. This connector is designed to support sustained mass production without frequent design changes.
With mature tooling and standardized production processes, this 1.25mm pitch DIP FPC connector supports large-scale manufacturing while maintaining consistent quality across batches.
Production advantages include:
Stable mold life and repeatable dimensions
High process control for contact alignment
Automated inspection for critical parameters
Consistent lead time for long-term projects
This makes it suitable for annual procurement contracts and long-term framework agreements.
Each connector undergoes strict quality control throughout the manufacturing process. Key performance indicators are verified to ensure reliable operation in demanding environments.
Quality management typically includes:
Dimensional accuracy inspection
Contact resistance testing
Mechanical retention evaluation
Solderability testing
Environmental reliability verification
These measures help reduce quality risk in large-scale production.
While the standard 15 pin 1.25mm DIP FPC connector meets most production needs, customization options are available for high-volume projects, including:
Contact plating thickness adjustment
Housing material selection
Cable orientation and locking structure optimization
Packaging customization for automated assembly
These options help manufacturers optimize cost, performance, and assembly efficiency.
Engineering support is available to assist with footprint design, mating cable selection, and production optimization. This ensures smooth integration into existing PCB layouts and reduces time spent on redesign or troubleshooting during mass production.
If you are sourcing a 15 pin 1.25mm pitch DIP FPC connector for large-scale production or long-term supply, M&T solution offers a reliable balance of performance, durability, and cost efficiency.
Bulk pricing, technical documentation, and samples are available upon request to support your procurement evaluation and validation process.
Core Technology
Key words:
Support USB3.2 10Gbps ultra-high-speed data transmission.
Core Advantage:
Right-angle PCB layout optimization: 90° mounting structure saves 40% board space and supports high-density wiring.
Technical Features:
Vbus/GND contacts support 5A current (PD3.0 100W fast charging).
Application Scenarios
