This dual-row through-hole (DIP) female header features a universal 2.54mm pitch design with 9 pins per row (18 pins total), optimized for traditional PCB through-hole soldering applications. With phosphor bronze gold-plated terminals ensuring superior conductivity and durability, it perfectly matches corresponding pin headers and is ideal for industrial equipment, instrumentation, and educational development boards.
Features
Gold-plated phosphor bronze terminals: Contact resistance ≤40mΩ per contact for reliable signal transmission.
Insulation resistance ≥1000MΩ at 100V for enhanced safety.
Universal 2.54mm pitch compatible with mainstream pin headers
Through-hole (DIP) design facilitates manual soldering and maintenance
UL94 V-0 flame-retardant black PPS housing.
Oxidation-resistant gold plating suitable for humid environments
Argument
| Material of Main Part/Color | PPS/Black |
| Number of Contacts | 9 Pin |
| Rated Current | 3Amps/ Contact MAX |
| Contact Resistance | 40mΩ MAX/Contact |
| Insulation Resistance | 1000MΩ Min. |
| Operating Temperature | -40℃~ +105℃ |
Core Technology
Key words:
Dual-row DIP Female Header
Core Advantage:
Engineered for stable signal transmission in harsh environments (humidity, vibration, extreme temperatures)
Application Scenarios
